SHD-GC 2kV Mining Cable

SHD-GC Cable is a flexible, heavy-duty mining cable designed for medium voltage portable power applications. It features durable insulation, grounding conductors, and a ground-check conductor for reliable power supply to longwall miners, drills, loaders, conveyors, pumps, shovels, and other mobile mining equipment in harsh working environments.

SKU: SHD-GC Category: Tags: , , , Brand:

SHD-GC 2kV Mining Cable

In both underground and open-pit mining environments, electrical infrastructure is subjected to extreme mechanical stresses, moisture, and chemical exposure. The SHD-GC 2kV Mining Cable by TEBAOFLEX is engineered specifically to handle these harsh conditions. Our heavy-duty portable power trailing cables offer reliable electricity distribution up to 2000V, ensuring that your high-capacity machines maintain continuous operation without unexpected downtime.

As a leading custom cable manufacturer with our own manufacturing facility, we specialize in high-performance power cables. The Mining Cable is constructed using premium raw materials and undergoes rigorous quality audits to exceed standard requirements, making it the preferred choice for purchasing managers worldwide.

SHD-GC 2kV Mining Cable Anatomy and Structure

SHD-GC 2kV Mining Cable structural cross section
SHD-GC 2kV Mining Cable structural cross section

To withstand extreme physical wear, our cable features a sophisticated multi-layer protective architecture. Below is the detailed breakdown of its construction:

  1. Power Conductors: Soft-drawn, extra-flexible stranded tinned copper wires. This specialized stranding ensures maximum bending flexibility and superior resistance to corrosion.
  2. Insulation Material: High-grade Ethylene-propylene rubber (EPR) rated for a continuous operating temperature of 90°C, offering excellent dielectric strength.
  3. Insulation Shielding: A non-conducting bedding tape coupled with a composite tinned copper and polyamide braid (with a minimum of 60% coverage). The polyamide threads are colored Black, Blue, and Red for clear phase identification.
  4. Uninsulated Grounding Conductors: Flexible stranded tinned copper wires placed in the interstices for safe, reliable grounding protection.
  5. Ground Check Conductor: A yellow TPE-E or PP insulated stranded tinned copper conductor (typically 8 AWG or custom sizes), designed to monitor ground continuity.
  6. Reinforced Outer Jacket: An extra heavy-duty, high-torsion resistant, two-layer CPE (chlorinated polyethylene) sheath reinforced with a robust Kevlar braid. Optional TPU jackets are also available for specific environmental needs.

SHD-GC 2kV Mining Cable Technical and Electrical Specifications

Below is a quick reference table of our standard sizes. We provide custom configurations from 14 AWG up to 500 MCM to match your equipment requirements:

Size (AWG/MCM) Cond. Strand No. Power Res. at $25^\circ\text{C}$ ($\Omega/1000\text{Ft}$) Inductance ($m\text{H}/1000\text{Ft}$) Capacitance ($\mu\text{F}/1000\text{Ft}$) Short-circuit Current (1s) ($k\text{A}$) Ampacity (40°C Ambient) ($A$)
6 AWG 133 0.436 0.118 0.09 1.90 93
4 AWG 259 0.274 0.107 0.11 3.03 122
2 AWG 259 0.172 0.101 0.13 4.80 159
2/0 AWG 342 0.0868 0.092 0.16 9.64 243
250 MCM 627 0.0466 0.084 0.21 18.16 355
500 MCM 1221 0.0233 0.078 0.28 36.18 536

Why Choose Our SHD-GC 2kV Custom Mining Cable?

Selecting the right cable manufacturer is vital to the safety and longevity of your operations. Our Mining Cable is manufactured in full compliance with international testing criteria, including ASTM and ICEA Standards. This ensures that every shipment meets the industry’s highest electrical safety benchmarks.

Key Quality and Performance Enhancements:

  • Severe Environment Resistance: Excellent protection against industrial oils, acid runoff, alkali soils, intense sunlight, flame propagation, and ozone degradation.
  • No Shape Memory: Designed to prevent “memory” effects when winding and unwinding on heavy-duty payout or retractable reels.
  • Outstanding Cold-Weather Flexibility: Maintains its high elastic property down to 40°C Ambient without jacket cracking.

Heavy-Duty Machinery and Application Scenarios

The TEBAOFLEX SHD-GC 2kV Mining Cable is the industry standard trailing cable for various high-stress mechanical equipment:

  • Underground Machinery: Continuous miners, longwall shearers, underground loaders, and tunneling jumbo drills.
  • Open-pit Operations: High-capacity draglines, heavy-duty loading shovels, and vertical rotary blast-hole drillers.
  • Logistics and Crane Systems: Container gantry cranes, suspended loop systems, and high-tension tension-controlled cable reels.

Export Packaging and Delivery Guarantee

Our factory packages trailing cables to withstand long-distance maritime transport. Standard packing consists of 500m continuous lengths on reinforced steel-wood drums, wrapped in water-resistant protective film. Custom lengths, custom color jackets, and tailored packaging solutions can be easily arranged to fit your exact project requirements.

To request detailed technical datasheets, CAD cross-section drawings, or a wholesale quotation, please contact our engineering team directly.
