XTRM (N)SHT11Y Crane Spreader PUR Cable 0.6/1 kV
Vertical-spreader PUR cable for harbour and container-crane duty, with aramid self-support, anti-torsion reinforcement, 160 m/min maximum stated speed and 20 kN breaking load. RFQ only: send the equipment, suspension height, travel profile and required core configuration for technical review.
The XTRM (N)SHT11Y is a 0.6/1 kV crane spreader cable for vertical suspension and fast moving service. Its fine-stranded copper conductors are combined with ETFE insulation, PUR inner and outer sheaths, polyester braid armour, aramid self-support and a synthetic anti-torsion braid. The approved data sheet states operation up to 160 m/min, suspension heights up to 90 m, a 20 kN breaking load and +/-50 deg/m torsion. The listed 37 x 2.5 + 1 x CAN-BUS BK build is supplied as part 054011. Request a technical quotation with the spreader type, suspension arrangement, travel speed, torsion profile, length and marking requirements.
Construction
- Exceptionally fine-stranded bare copper conductors.
- ETFE conductor insulation.
- PUR inner sheath with polyester braid armour.
- Aramid self-support layer for suspended crane service.
- Synthetic anti-torsion braid and black PUR outer sheath.
Applications
- Vertical spreader and container-crane cable systems.
- Harbour-crane installations with suspended cable lengths up to 90 m as stated in the data sheet.
- High-speed moving service up to 160 m/min where the stated installation geometry is maintained.
- Duty profiles requiring controlled torsion of 卤50 deg/m.
Specifications
| Rated voltage | 0.6/1 kV; maximum 1.2 kV three-phase |
|---|---|
| Test reference | 3.5 kV |
| Conductor temperature | 90 掳C; 250 掳C short-circuit reference |
| Temperature, fixed | -50 to +80 掳C |
| Temperature, moving | -35 to +80 掳C |
| Minimum bend geometry | S-changeover 20 脳 OD; single bend 4 脳 OD; moving bend 5 脳 OD |
| Torsion | 卤50 deg/m |
| Maximum stated speed | 160 m/min |
| Suspension height | Up to 90 m |
| Breaking load | 20 kN |
| Listed configuration | Part 054011: 37 x 2.5 + 1 x CAN-BUS BK |
| Approximate outside diameter | 30 mm |
| Current rating | 30 A in air at 30 掳C |
| Copper / net weight | Cu 1045 kg/km; net 1575 kg/km |
Standards
- 3.5 kV test reference as stated in the supplied product data.
- UV, oil, ozone and water resistance are stated product properties in the supplied data.
- Temperature, bend, torsion, speed, suspension and tensile figures are source-data references for selection and quotation.
