SiF Silicone 180 Single Core Flexible Cable

SiF Silicone 180 Single Core Flexible Cable is a TEBAOFLEX cable for the application and operating conditions identified in the original product record. SiF Silicone 180 cable is available in a wide range of single core conductor sizes, including 0.5mm², 0.75mm², 1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm² and 300mm². SiF cable is a single core silicone rubber insulated cable designed for high temperature wiring in lamps, heating equipment, electrical appliances, switch boxes and distribution boards. The source record places this product in high temperature cables. Before ordering, confirm the exact product variant, conductor or core arrangement, system rating, route conditions, equipment connection and required documentation against the project specification. The requested SiF Silicone 180 Single Core Flexible Cable should be evaluated as a complete cable assembly: review its intended equipment, conductor arrangement, installation method, movement duty, environment, terminations, dimensions and required documentation together. The V2 layout keeps the source-listed construction, application, technical and standard information available for a controlled engineering and procurement review. Use the Request Quote section to confirm the exact configuration, route conditions and documentation requirements before production or replacement ordering.

SiF Silicone 180 Single Core Flexible Cable construction

Cable Construction

1. Conductor: Class 5 flexible stranded tinned copper conductor.
2. Insulation: Silicone rubber insulation for high temperature internal wiring.
3. Colour Options: Green/yellow, blue, black, brown, grey, white and red.

SiF Silicone 180 Single Core Flexible Cable applications

Applications

• Internal wiring of lamps and lighting equipment
• Heating equipment and high temperature appliances
• Switch boxes and distribution boards
• Electrical equipment operating above 55°C ambient temperature
• Control cabinet and equipment wiring requiring flexible silicone wire
• Fixed wiring where standard PVC wire is not suitable because of heat exposure

Totally enclosed appliance wiring that stays within 105°C and is drawn to a UL style rather than a SiF designation can be checked against the UL 3232 silicone appliance wire, a 300 V AC construction with tinned stranded copper and silicone-rubber insulation.

Selection checks

Confirm the equipment interface, installation method, route length, movement or flexing duty, environmental exposure, conductor or core requirements and project documentation before final selection.

SiF Silicone 180 Single Core Flexible Cable specifications

The source-listed technical notes are retained below. Confirm the final size, tolerance, installation basis and ordered configuration before release.

SiF Cable for High Temperature Internal Wiring

SiF cable is a 300/500V single core silicone rubber insulated cable used for operation in ambient temperatures above 55°C. It is suitable for internal wiring of lamps, heating equipment, electrical appliances, switch boxes and distribution boards where standard PVC insulated wire may not provide sufficient heat resistance.

Available Size Options

SiF Silicone 180 cable is available in a wide range of single core conductor sizes, including 0.5mm², 0.75mm², 1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm² and 300mm².

Source-listed technical tables

The tables below retain the original product data, including units, ranges and ordering examples.

SiF Silicone 180 Single Core Flexible Cable standards and compliance

The following standard references are carried over from the original product record. They identify the source basis and do not replace project-specific certification or inspection requirements.

• Flame retardant performance: Flame retardant according to IEC 60332-1-2.
• Standard VDE 0482-332-1-2
• Flame Retardant Standard IEC 60332-1-2

Where a project requires a test report, certificate, marking record or inspection release, include that requirement in the quotation request.
